HPE M-series Q2F19A Compatible 100Gbps QSFP28 100GBASE-SR4 850nm 100m MMF MTP/MPO-12 DDM/DOM Optical Transceiver Module HPE M-series Q2F19A compatible optical transceiver is a parallel 100Gbps Quad Small Form-factor Pluggable QSFP28 module for use in 100GBASE Ethernet network. QSFP28 SR4 provides 103.1Gb/s throughput up to 100 meters over OM4 or 70 meters over OM3 multi-mode fiber (MMF) with host FEC using 850nm wavelength. This transceiver is fully compliant with QSFP28 Multi-Source Agreement (MSA), IEEE 802.3bm 100GBASE-SR4 and CAUI-4 standard. Its electrical interface is MSA compliant 38-pin edge type connector and the optical interface is MTP/MPO-12 connector. The full-duplex QSFP28 transceiver implements 4 independent 25.78125Gbps transmit and receive signal channels in each fiber for an aggregate 103.125Gbps data rate. Built-in Digital Diagnostic Monitoring/Digital Optical Monitoring (DDM/DOM) support is present for real-time performance monitoring via 2-wire (TWI/I2C) interface. Our modules are factory pre-programmed for compatibility, perform alternatively to genuine HPE M-series Q2F19A transceivers. Feature Equivalent to HPE M-series Q2F19A in function Hot pluggable QSFP28 fiber optic transceiver module Aggregate data rate up to 103.125Gbps 4 channels 850nm VCSEL transmitter 4 channels PIN photo receiver MTP/MPO-12 optical connector Link distance up to OM4 100m, OM3 70m with host FEC 4x 25.78125Gbps NRZ retimed CAUI-4 electrical interface Built-in digital diagnostic via 2-wire interface Single 3.3V power supply voltage Power consumption Ambient temperature range 0 to 70°C for commercial application Compliant with SFF-8665, SFF-8661, SFF-8679, SFF-8636 Compliant with IEEE 802.3bm 100GBASE-SR4 Compliant with RoHS, REACH, CE, FCC standards Application 100G Ethernet Data Center Specification HPE M-series Compatible P/N Q2F19A Form Factor QSFP28 Max Data Rate 103.125Gbps Max Distance 100m (328ft) @OM4, 70m (230ft) @OM3 Wavelength 850nm Connector MTP/MPO-12 DDM/DOM Support Media MMF Transmitter Type 4x VCSEL Receiver Type PIN Transmitter Power -8.4 to 2.4dBm Receiver Sensitivity < -10.3dBm Extinction Ratio 3dB Receiver Overload 2.4dBm Transmit and Dispersion Penalty 5dB Power Budget 1.9dB OE Packaging COB Packaging Signal Conditioner Retimer for TX and RX Modulation Format NRZ Host FEC Support Power Consumption 3.5W Commercial Temperature Range 0 to 70°C (32 to 158°F)
