HPE M-series Q6M30A Compatible 10Gbps SFP 10GBASE-SR 850nm 300m MMF Duplex LC DDM/DOM Optical Transceiver Module HPE M-series Q6M30A compatible optical transceiver is a dual fiber 10Gbps Small Form-factor Pluggable SFP module for use in 10GBASE Ethernet network. SFP SR provides 10.31Gb/s throughput up to 300 meters over OM3 or 82 meters over OM2 multi-mode fiber (MMF) using 850nm wavelength. This transceiver is fully compliant with SFP Multi-Source Agreement (MSA), IEEE 802.3ae 10GBASE-SR and SFI standard. Its electrical interface is MSA compliant 20-pin edge type connector and the optical interface is Duplex LC connector. The full-duplex SFP transceiver features highly reliable VCSEL transmitter and PIN photo detector to offer high performance interconnection at 10.3125Gbps data rate. Built-in Digital Diagnostic Monitoring/Digital Optical Monitoring (DDM/DOM) support is present for real-time performance monitoring via 2-wire (TWI/I2C) interface. Our modules are factory pre-programmed for compatibility, perform alternatively to genuine HPE M-series Q6M30A transceivers. Feature Equivalent to HPE M-series Q6M30A in function Hot pluggable SFP fiber optic transceiver module Data rate up to 10.3125Gbps 850nm VCSEL transmitter PIN photo receiver Duplex LC optical connector Link distance up to OM3 300m Built-in digital diagnostic via 2-wire interface Single 3.3V power supply voltage Power consumption Ambient temperature range 0 to 70°C for commercial application Compliant with SFF-8431, SFF-8432, SFF-8419, SFF-8472 Compliant with IEEE 802.3ae 10GBASE-SR Compliant with RoHS, REACH, CE, FCC standards Application 10G Ethernet 10G Fibre Channel over Ethernet 10G SONET/SDH Enterprise Campus 10G CPRI Data Center Specification HPE M-series Compatible P/N Q6M30A Form Factor SFP Max Data Rate 10.3125Gbps Max Distance 300m (984ft) @OM3 Wavelength 850nm Connector Duplex LC DDM/DOM Support Media MMF Transmitter Type VCSEL Receiver Type PIN Transmitter Power -7.3 to -1dBm Receiver Sensitivity < -11.1dBm Extinction Ratio 3dB Receiver Overload -1dBm Transmit and Dispersion Penalty 3.9dB Power Budget 3.8dB OE Packaging Coaxial Packaging Modulation Format NRZ Power Consumption 1W Commercial Temperature Range 0 to 70°C (32 to 158°F)
