Technical Specifications Mechanical Dimensions 118.3 x 46.8 x 25.8 mm (4.7 x 1.8 x 1″) Weight Without mount: 130 g (4.59 oz) With flat wall mount: 178 g (6.28 oz) With 20° wedge mount: 200 g (7.05 oz) Enclosure material Polycarbonate Mount materials Flat wall mount: aluminum alloy 20° wedge mount: polycarbonate Weatherproofing IPX4 Optics Sensor 5MP CMOS sensor Lens Fixed focal length View angle H: 138°, V: 114°, D: 155° Night mode Built-in IR LED illumination and IR cut filter Video Video compression H.264 Resolution 1600 x 1200 (4:3) Max. frame rate 30 FPS System Processor Quad-core Arm® Cortex®-A53 based chip Networking interface 802.11a/b/g/n/ac WiFi Bluetooth™ 4.2 Max. power consumption 12W Power requirements 16—24V AC, 1.25A max., 50/60 Hz Supported voltage range 16—24V AC LED Link/activity Buttons (1) Ring button (1) Factory reset Mounting Flat wall, 20° wedge (Included) Operating temperature -10 to 40º C (14 to 104º F) Operating humidity 0 to 90% noncondensing Certifications FCC, IC, CE Audio Microphone Yes (Can be disabled) Speaker Yes Software Web application UniFi Protect Mobile app UniFi Protect iOS™ and Android™ Compatible Mechanical Chimes Manufacturer Broan-NuTone Broan-NuTone Heath Zenith Craftmade Broan-NuTone Newhouse Hardware Model LA126WH LA11WH SL-2735 CTPW-RG LA39WH CHM3D Compatible Digital Chimes Manufacturer Broan-NuTone IQ AMERICA IQ AMERICA Model LA600WH DW-2850 DW-2840 Transformer Specifications (EU Version) Input rating (5, 6) 230V, 50/60Hz Output rating (1, 4) 16V AC, 15VA Operating temperature -5 to 35 º C (23 to 95º F)
