1m (3.28ft) Huawei QSFP-100G-AOC1M Compatible QSFP28 to QSFP28 AOC 100GBASE-CR4 100Gbps Multi Mode Fiber Active Optical Cable

1m (3.28ft) Huawei QSFP-100G-AOC1M Compatible QSFP28 to QSFP28 AOC 100GBASE-CR4 100Gbps Multi Mode Fiber Active Optical Cable Huawei QSFP-100G-AOC1M compatible AOC is a 100Gbps QSFP28 to QSFP28 active optical cable for use in 100GBASE Ethernet network. QSFP28 AOC provides 103.1Gb/s throughput for 1m interconnection with laser-optimized multi-mode fiber optical cable. This AOC is fully compliant with QSFP28 Multi-Source Agreement (MSA), IEEE 802.3bj 100GBASE-CR4 and CAUI-4 standard. Its optical fiber cable is pre-terminated with MSA compliant 38-pin edge type connectors. The AOC cable implements 4 independent 25.78125Gbps NRZ transmit and receive signal channels in each fiber for an aggregate 103.125Gbps data rate. Standard length options cover from 1 meter to 30 meters. Built-in Digital Diagnostic Monitoring/Digital Optical Monitoring (DDM/DOM) support is present for real-time performance monitoring via 2-wire (TWI/I2C) interface. Our AOCs are factory pre-programmed for compatibility, perform alternatively to genuine Huawei QSFP-100G-AOC1M active optical cables. Feature Equivalent to Huawei QSFP-100G-AOC1M in function Hot pluggable QSFP28 to QSFP28 AOC active optical cable Aggregate data rate up to 103.125Gbps Pre-terminated multi-mode fiber cable 4x 25.78125Gbps NRZ retimed CAUI-4 electrical interface Minimum bending radius 7.5mm Built-in digital diagnostic via 2-wire interface Single 3.3V power supply voltage Power consumption Ambient temperature range 0 to 70°C for commercial application Compliant with SFF-8665, SFF-8661, SFF-8679, SFF-8636 Compliant with IEEE 802.3bj 100GBASE-CR4 Compliant with RoHS, REACH, CE, FCC standards Application 100G Ethernet Data Center Specification Huawei Compatible P/N QSFP-100G-AOC1M Topology QSFP28 to QSFP28 Max Data Rate 103.125Gbps Cable Length 1m (3.28ft) Cable Type OM3 Multi Mode Fiber Jacket Meterial OFNP Minimum Bend Radius 7.5mm Signal Conditioner Retimer for TX and RX Modulation Format NRZ Host FEC Support Power Consumption 3.5W Commercial Temperature Range 0 to 70°C (32 to 158°F)
