IBM 00WC086 Compatible 1.25Gbps SFP 1000BASE-T 100m CAT6/CAT6a RJ45 Copper Transceiver Module

IBM 00WC086 Compatible 1.25Gbps SFP 1000BASE-T 100m CAT6/CAT6a RJ45 Copper Transceiver Module IBM 00WC086 compatible copper transceiver is a single channel 1000Mbps Small Form-factor Pluggable SFP module for use in 1000BASE Ethernet network. SFP GE-T provides 1Gb/s throughput up to 100 meters over CAT5e/CAT6 twisted network cable. This transceiver is fully compliant with SFP Multi-Source Agreement (MSA), IEEE 802.3ab 1000BASE-T and SERDES standard. Its electrical interface is MSA compliant 20-pin edge type connector and the line-side interface is RJ45 connector. The full-duplex SFP transceiver offers high performance interconnection at 1.25Gbps data rate. Low power consumption (1.05W for 100m) suits various brands of hosts, widely used in data centers and enterprise networks. MSA memory map is accessible via 2-wire (TWI/I2C) interface. Our modules are factory pre-programmed for compatibility, perform alternatively to genuine IBM 00WC086 transceivers. Feature Equivalent to IBM 00WC086 in function Hot pluggable SFP copper transceiver module Data rate up to 1.25Gbps Conversion between host-side 1000BASE-X and line-side 1000BASE-T RJ45 connector Auto-sense MDI/MDIX and auto-negotiation Supports 1000BASE-T using 100m Cat 5e/6 cable MSA memory accessible via 2-wire interface Single 3.3V power supply voltage Low power consumption (typically 1.05W @ 1000Mbps 100m) Ambient temperature range 0 to 70°C for commercial application Compliant with INF-8074i, SFF-8472 Compliant with IEEE 802.3ab 1000BASE-T Compliant with RoHS, REACH, CE, FCC standards Application Gigabit Ethernet Enterprise Campus Data Center Specification IBM Compatible P/N 00WC086 Form Factor SFP Max Data Rate 1.25Gbps Max Distance 100m (328ft) Connector RJ45 Media CAT6/CAT6a Modulation Format PAM5 DDM/DOM Not support Power Consumption 1.05W Commercial Temperature Range 0 to 70°C (32 to 158°F)
