IBM Lenovo 00D6222 Compatible 40Gbps QSFP 40GBASE-LR4 1310nm 10km SMF Duplex LC DDM/DOM Optical Transceiver Module IBM Lenovo 00D6222 compatible optical transceiver is a parallel 40Gbps Quad Small Form-factor Pluggable QSFP module for use in 40GBASE Ethernet network. QSFP LR4 provides 41.2Gb/s throughput up to 10km over single-mode fiber (SMF) using 1271nm, 1291nm, 1311nm, 1331nm wavelength. This transceiver is fully compliant with QSFP Multi-Source Agreement (MSA), IEEE 802.3ba 40GBASE-LR4 and XLPPI standard. Its electrical interface is MSA compliant 38-pin edge type connector and the optical interface is Duplex LC connector. The full-duplex QSFP transceiver implements 4 independent 10.3125Gbps transmit and receive signal channels in each wavelength for an aggregate 41.25Gbps data rate. Built-in Digital Diagnostic Monitoring/Digital Optical Monitoring (DDM/DOM) support is present for real-time performance monitoring via 2-wire (TWI/I2C) interface. Our modules are factory pre-programmed for compatibility, perform alternatively to genuine IBM Lenovo 00D6222 transceivers. Feature Equivalent to IBM Lenovo 00D6222 in function Hot pluggable QSFP fiber optic transceiver module Aggregate data rate up to 41.25Gbps 4 channels 1310nm CWDM DML transmitter 4 channels PIN photo receiver Duplex LC optical connector Link distance up to SMF 10km 4x 10.3125Gbps NRZ XLPPI electrical interface Built-in digital diagnostic via 2-wire interface Single 3.3V power supply voltage Power consumption Ambient temperature range 0 to 70°C for commercial application Compliant with SFF-8436, SFF-8635, SFF-8661, SFF-8679, SFF-8636 Compliant with IEEE 802.3ba 40GBASE-LR4 Compliant with RoHS, REACH, CE, FCC standards Application 40G Ethernet OTN G.709 OTU3 Data Center Specification IBM Lenovo Compatible P/N 00D6222 Form Factor QSFP Max Data Rate 41.25Gbps Max Distance 10km (6.2 miles) Wavelength 1271nm, 1291nm, 1311nm, 1331nm Connector Duplex LC DDM/DOM Support Media SMF Transmitter Type 4x CWDM DML Receiver Type PIN Transmitter Power -7 to 2.3dBm Receiver Sensitivity < -11.5dBm Extinction Ratio 4.5dB Receiver Overload 3.3dBm Transmit and Dispersion Penalty 2.6dB Power Budget 4.5dB OE Packaging Box Packaging Modulation Format NRZ Power Consumption 3.5W Commercial Temperature Range 0 to 70°C (32 to 158°F)
