IBM Lenovo 00FE325 Compatible 40Gbps QSFP 40GBASE-SR4 850nm 400m MMF MTP/MPO-12 DDM/DOM Optical Transceiver Module IBM Lenovo 00FE325 compatible optical transceiver is a parallel 40Gbps Quad Small Form-factor Pluggable QSFP module for use in 40GBASE Ethernet network. QSFP ESR4 provides 41.2Gb/s throughput up to 400 meters over OM4 multi-mode fiber (MMF) using 850nm wavelength. This transceiver is fully compliant with QSFP Multi-Source Agreement (MSA), IEEE 802.3ba 40GBASE-SR4 and XLPPI standard. Its electrical interface is MSA compliant 38-pin edge type connector and the optical interface is MTP/MPO-12 connector. The full-duplex QSFP transceiver implements 4 independent 10.3125Gbps transmit and receive signal channels in each fiber for an aggregate 41.25Gbps data rate. Built-in Digital Diagnostic Monitoring/Digital Optical Monitoring (DDM/DOM) support is present for real-time performance monitoring via 2-wire (TWI/I2C) interface. Our modules are factory pre-programmed for compatibility, perform alternatively to genuine IBM Lenovo 00FE325 transceivers. Feature Equivalent to IBM Lenovo 00FE325 in function Hot pluggable QSFP fiber optic transceiver module Aggregate data rate up to 41.25Gbps 4 channels 850nm VCSEL transmitter 4 channels PIN photo receiver MTP/MPO-12 optical connector Link distance up to OM4 400m 4x 10.3125Gbps NRZ XLPPI electrical interface Built-in digital diagnostic via 2-wire interface Single 3.3V power supply voltage Power consumption Ambient temperature range 0 to 70°C for commercial application Compliant with SFF-8436, SFF-8635, SFF-8661, SFF-8679, SFF-8636 Compliant with IEEE 802.3ba 40GBASE-SR4 Compliant with RoHS, REACH, CE, FCC standards Application 40G Ethernet OTN G.709 OTU3 Data Center Specification IBM Lenovo Compatible P/N 00FE325 Form Factor QSFP Max Data Rate 41.25Gbps Max Distance 400m (1312ft) @OM4 Wavelength 850nm Connector MTP/MPO-12 DDM/DOM Support Media MMF Transmitter Type 4x VCSEL Receiver Type PIN Transmitter Power -7.5 to 0dBm Receiver Sensitivity < -9.9dBm Extinction Ratio 3dB Receiver Overload 2dBm Transmit and Dispersion Penalty 3.5dB Power Budget 2.4dB OE Packaging COB Packaging Modulation Format NRZ Power Consumption 1.2W Commercial Temperature Range 0 to 70°C (32 to 158°F)
