IBM 00MJ105 Compatible 8Gbps SFP 800-SM-LC-L 1310nm 10km SMF Duplex LC DDM/DOM Optical Transceiver Module IBM 00MJ105 compatible optical transceiver is a dual fiber 8Gbps Small Form-factor Pluggable SFP module for use in 8G Fibre Channel network. SFP 8G-LW provides 8.5Gb/s throughput up to 10km over single-mode fiber (SMF) using 1310nm wavelength. This transceiver is fully compliant with SFP Multi-Source Agreement (MSA), FCIA FC-PI-4 800-SM-LC-L and SFI standard. Its electrical interface is MSA compliant 20-pin edge type connector and the optical interface is Duplex LC connector. The full-duplex SFP transceiver features highly reliable DFB transmitter and PIN photo detector to offer high performance interconnection at 8.5Gbps data rate. Built-in Digital Diagnostic Monitoring/Digital Optical Monitoring (DDM/DOM) support is present for real-time performance monitoring via 2-wire (TWI/I2C) interface. Our modules are factory pre-programmed for compatibility, perform alternatively to genuine IBM 00MJ105 transceivers. Feature Equivalent to IBM 00MJ105 in function Hot pluggable SFP fiber optic transceiver module Data rate up to 8.5Gbps 1310nm DFB transmitter PIN photo receiver Duplex LC optical connector Link distance up to SMF 10km Built-in digital diagnostic via 2-wire interface Single 3.3V power supply voltage Power consumption Ambient temperature range 0 to 70°C for commercial application Compliant with SFF-8431, SFF-8432, SFF-8419, SFF-8472 Compliant with FCIA FC-PI-4 800-SM-LC-L Compliant with RoHS, REACH, CE, FCC standards Application 8G Fibre Channel 4G Fibre Channel 2G Fibre Channel Enterprise Campus Data Center Specification IBM Compatible P/N 00MJ105 Form Factor SFP Max Data Rate 8.5Gbps Max Distance 10km (6.2 miles) Wavelength 1310nm Connector Duplex LC DDM/DOM Support Media SMF Transmitter Type DFB Receiver Type PIN Transmitter Power -8 to 0dBm Receiver Sensitivity < -15dBm Extinction Ratio 3.5dB Receiver Overload 0.5dBm Transmit and Dispersion Penalty 3.2dB Power Budget 7dB OE Packaging Coaxial Packaging Modulation Format NRZ Power Consumption 1W Commercial Temperature Range 0 to 70°C (32 to 158°F)
